Calabar
Calabar
Braiding
Non-braided
Material
Rubber Hose
Diameters available
DN6
to
DN25
1/4"inch
to
1inch
Temperature
-40
°C
to
88
°C
Pressure
bar
to
bar
Medium
Liquid
Environment
Ambient & Vacuum
Show measures in:
Braiding:
Diameter [DN]
6
10
12
16
20
25
Diameter [inch]
1/4"
3/8"
1/2"
5/8"
3/4"
1"
Stub outside diameter [mm]
13.2
16.4
19.6
22.4
26.0
32.4
Hose inner diameter [mm]
6.7
10.0
13.2
16.0
19.0
25.4
Hose outside diameter [mm]
13.2
16.4
19.6
22.4
26.0
30.4
Static bend radius [mm]
65.0
75.0
125.0
150.0
180.0
250.0
